ClearFire®-CE Boiler
.png)
- Input Capacity (MBH): 500 - 6,000
- Steam or Hot Water: Hot Water
- Vessel Design: Firetube
- Number of Passes: 1
- Design Temperature (deg F): 210
- Fuel: Natural Gas, Propane, Combination firing
- Emissions (ppm NOx): <20 ppm standard, lower emission optional
- AHRI Thermal Efficiency (%): 96
- AHRI Combustion Efficiency (%): 94.7
- Fully condensing high-mass firetube boiler
- TurboFer® heat exchanger with new integrated Ember controls
- 11 models from 500 MBH to 6,000 MBH
- 10:1 fully modulating turndown
- Future-proof fuel flexibility and compact design
- Standard less than 20 ppm NOx, sub 7 ppm NOx available
- Ideal for variable flow primary systems
- 24/7 remote connectivity available
The latest generation of the ClearFire-CE is a compact, high-mass, fully condensing hydronic boiler, featuring patented TurboFer® heat exchanger technologies with innovative integrated Ember controls, allowing for maximum operating efficiency in a variety of system applications and ensuring heat transfer done right.
Download the new ClearFire®-CE Boiler Brochure
The CFC-E is up to 99% efficient due to its high-mass firetube construction with TurboFer technology. It is simple to install and integrate into a system due to its robust, low flow tolerant design. The burner design and controls offer future-proof fuel flexibility that can support renewable natural gas and up to 20% volumetric mix hydrogen-natural gas blends.
- CFCE AHRI Certified Ratings(Literature)
- CFC-E Installation Manual(Technical Data)
- CFC-E Maintenance Manual(Technical Data)
- CFC-E Master Schedule(Technical Data)
- CFC-E Startup Manual(Technical Data)
- CFC-E Warranty Coverage(Literature)
- CFC-E with Falcon Controls - Installation Manual(Technical Data)
- CFC-E with Falcon Controls - Maintenance Manual(Technical Data)
- CFC-E with Falcon Controls - Reference Manual(Technical Data)
- CFC-E with Falcon Controls - Startup Manual(Technical Data)
- CFC-E with Falcon Controls Brochure(Literature)
- ClearFire® Hydronic Available Stock(Literature)
- ClearFire®-CE Boiler Book(Technical Data)
- ClearFire®-CE Brochure(Literature)
- ClearFire®-CE Dimensions and Ratings(Technical Data)
- ClearFire®-CE Specifications(Technical Data)
- ClearFire-CE ADSK Files(Drawings)
- ClearFire-CE DWG Files(Drawings)
- ClearFire-CE STEP Files(Drawings)
- Contractor Brochure(Literature)
- Hydronic Solutions Brochure(Literature)
- Hydronics Reference Guide(Literature)
- Key Considerations for Hydronic Closed Loop Systems - White Paper(Literature)
- ProtoAir Gateway Manual(Technical Data)
- Protonode Gateway Manual(Technical Data)
- SCAQMD Listing(Literature)
- Total System Efficiency - Condensing Boiler System Mythbusting(Literature)
- Total System Efficiency - Condensing Boilers in Retrofit Applications(Literature)
- Total System Efficiency - Control Strategies and System Distribution(Literature)
- Total System Efficiency - Introduction(Literature)
- Total System Efficiency - New Design Paradigm(Literature)
- Total System Efficiency - System Applications and Designs(Literature)
- Product Overview
- Related Resources
- Applications
- System engineering flexibility with large water capacity and dual returns
- Duplex stainless steel construction
- Hinged burner for easy access
- Non-prorated warranties
- Low waterside pressure drop for reduced pumping energy requirements
- Boiler room space savings with 3 inch side clearance
- Inherent O2 trim
- Quiet operation, <70 dBA sound level at 3 feet
The ClearFire-CE (CFC-E) with TurboFer ensures heat transfer done right. The industry leading firetube design creates turbulence in the tubes, enhancing the flue gas heat transfer characteristics. It combines the AluFer® tube technology to significantly increase the effective heat transfer surface area up to five times greater than other condensing boilers, with a thermal conductivity ten times greater than stainless steel alone. These advancements result in a highly compact firetube boiler designed to maximize energy savings and offer high condensing performance. The TurboFer technology, along with new integrated Ember controls, has been introduced in the ClearFire boilers, which have been tried and tested for 20+ years.
The new model consists of a large water capacity, thermal shock proof pressure vessel, capable of high-delta-T system designs to maximize condensing and reduce flow rates. The linkage-less burner provides fully modulating 10:1 turndown as standard without the use of complex air/fuel mixing valves. With its small overall footprint, the CFC-E is ideal for retrofit applications, and designed to leverage the advantages of primary-variable-flow pumping systems. This design offers system flexibility and true operational efficiency without compromise, making it an excellent choice for a variety of applications.
